City & Commuter E-Bikes

FALCON ZR-CP060

This lightweight electric commuter bike features an alu […]

Motor
350 W rated; 36 V 350 W hub motor
Battery
36 V 10.4 Ah Li-ion
Maximum Load / Payload
150 kg
Tire / Wheel
24-inch wheels; 24 × 2.35 in (58-507) tube-type tires
REQUEST A QUOTE OEM / ODM
FULL TECHNICAL SPECIFICATIONS

Verified model details.

POWER & PERFORMANCE

Product Reference
ZR-CP060
Motor
350 W rated; 36 V 350 W hub motor
Battery
36 V 10.4 Ah Li-ion
Display
VA display
Climbing Ability
15°
Maximum Load / Payload
150 kg
Maximum Speed
25 km/h
Range / Mileage
40 km

CHASSIS & COMPONENTS

Frame
Aluminum alloy
Tire / Wheel
24-inch wheels; 24 × 2.35 in (58-507) tube-type tires
Hub
24 × 1.75 in double-wall aluminum rim
Brake / Braking
Aluminum mechanical disc brakes
Suspension / Fork
Aluminum crown; textured matte-black powder coating; 28.6 mm CP steel inner tube
Light
//

DIMENSIONS & LOGISTICS

Size / Dimensions
1580 × 680 × 1050 mm
Net Weight
18 kg
Ground Clearance
270 mm
Rear Axle
//
Wheelbase
1020 mm
Track Width
//
Container Loading
250 units / 40-ft high-cube container

ADDITIONAL VERIFIED DETAILS

Manufacturer Model
Black Eagle
Gross Weight
//
Outer Carton Material
Kraft carton
Inner Color Box Material
//
Outer Carton Dimensions
1350 × 240 × 750 mm
Folded Vehicle Dimensions
//
Seat Height from Ground
770 mm
Drive Control
Pedal assist
Motor Rated Voltage
36 V
Motor Maximum RPM
//
Motor Maximum Output Torque
//
Wheel Construction
Inner tube
Braking Distance
≤4 m
Transmission
Shimano Tourney RD-TY300; 6/7-speed
Bluetooth
//
Audio System
//
Frame Color
Customizable
Minimum Order Quantity
100 units
PRODUCT OVERVIEW

FALCON ZR-CP060

This lightweight electric commuter bike features an aluminum alloy frame, 350W hub motor, and 36V 10.4Ah lithium battery. Weighing only 18 kg, it offers a top speed of 25 km/h, approximately 40 km of riding range, front suspension, and mechanical disc brakes for comfortable everyday city commuting.
