City & Commuter E-Bikes

FALCON ZT-CP015

A step-through 26-inch city e-bike with rear rack, disc brakes and a 350 W rated motor.

Motor: 350 W rated / 500 W peak hub motor
Battery: 48 V 10.4 Ah Li-ion
Maximum Load / Payload: 150 kg
Tire / Wheel: 26-inch wheels / inner tubes

REQUEST A QUOTE OEM / ODM

FULL TECHNICAL SPECIFICATIONS

Verified model details.

POWER & PERFORMANCE

Product Reference: ZT-CP015
Motor: 350 W rated / 500 W peak hub motor
Battery: 48 V 10.4 Ah Li-ion
Display: Digital display
Maximum Load / Payload: 150 kg
Maximum Speed: 40 km/h / Shimano 7-speed
Range / Mileage: 50 km

CHASSIS & COMPONENTS

Frame: High-Carbon Steel
Tire / Wheel: 26-inch wheels / inner tubes
Hub: Aluminum-alloy wheel construction
Brake / Braking: Disc brakes; braking distance < 4 m
Light: LED headlight

DIMENSIONS & LOGISTICS

Size / Dimensions: 1,790 × 690 × 890 mm
Net Weight: 12 kg
Ground Clearance: 210 mm
Wheelbase: 1,100 mm
Container Loading: 200 units / 40-ft high-cube container

ADDITIONAL VERIFIED DETAILS

Seat Height from Ground: 830 mm
Gradeability: 15°
Drive Control: Twist throttle, stepless
Transmission: Shimano 7-speed
Wheel Construction: Inner tube
Frame Color: Customization available
Minimum Order Quantity: 100 units

PRODUCT OVERVIEW

Step-Through Electric City Bike with Rear Rack & Disc Brakes-ZT-CP015

The FALCON ZR-CP015 combines a step-through city frame, rear cargo rack and disc brakes with a 350 W rated hub motor. Its 48 V 10.4 Ah lithium battery, Shimano 7-speed drivetrain and configurable finish support city, fleet and private-label programs.
